Use:
    STYE-2000 Digital Display Hydraulic Compression Testing Machine is designed to conduct compression and crushing strength tests on Containers, Concrete cubes, cylinders, hollow blocks and various other materials in accordance with International standard. The machine is electro-hydraulically operated. The control panel comprises of hydraulic power pack, digital readout system, operating switches, load control valves, output print-out of test data.

Specification:
1.Max. testing power: 2000kN
2.Measuring range: 0-2000kN
3.Relative indication error: ±1%
4.Testing power Precision:grade1，grade0.5
5.Size of the bearing plate: 320×260mm
6.Max. distance between the up and down bearing
7.Plates: 310mm
8.Max. piston stroke: 90mm
9.Rated pressure of the hydraulic pump: 40MPa
10.Power: AC220V±10% or AC380±10%
11.Outside size: 950×400×1160mm
12.Max. piston lift speed: 50mm/min.
13.Piston free back speed: 20mm/min.
14.Net weight: about 850KGS
15.Noise: ≤80Db
